Product data sheet

HELIOS 360 MO 3K

E7508023

Cardi

Product image 1: HELIOS 360 MO 3K
Product image 1: HELIOS 360 MO 3K

Product image 1: HELIOS 360 MO 3K



IP
44

IK
06

Plafond IP44 för inomhusbruk. Stomme av vitlackerad stålplåt. Kupa av opal akryl med vridfastsättning. Monteras dikt tak eller på vägg. 2st kabelinföringar Ø 20 mm på baksidan. Förberedd för utanpåliggande kabel, 2st knock-out Ø 13 mm. Insticksplint 3x3x2,5 mm². Möjlighet till dos-montage samt förberedd för utanpåliggande kabel. Armaturen är dimbar med extern dimmer med bakkantsreglering.

Lamp type Nominal lamp power Total flux Luminous efficacy CCT CRI
LED 18 W 1930 lm 107 lm/W 3000 K 80
HELIOS 360 MO 3K

HELIOS 360 MO 3K

Light output 1 (integrated)

LED

Mounting mode

Ceiling mounted

Shape and measurements

Length: 358 mm

Width: 358 mm

Height: 72 mm

Adjustability

Fixed

Electric

System power: 18 W

Appliance Class: I

Protection

IP: 44

IK: 06

Photometric data

ZIP file

Download file
