Light source LED 5400 - 8100 lumen out Colour temperature 4000 K, CRI Ra 80, MacAdams 3 On request: 3000 K Driver Fixed output (HF) and DALI dimmable (1-100%). Driver life time up to 120.000 h/10 % (max failure) at Ta 25°C. Body material & colour Housing in Aluzink or acid-proof steel with white epoxy/polyester powder coated finish. Alternatively in unpainted acid-proof steel. Tempered 5 mm safety glass cover with silicone gasket, spring-loaded acid proof steel clips and safety wires. Mounting The luminaire is supplied with fixed end brackets. Accessories Suspension kits. Connection 5 pole 6 mm² screw terminal block. 5 x 2,5 mm² through wiring. 5-way chassis plug in both ends on request.
Lamp type | Nominal lamp power | Total flux | Luminous efficacy | CCT | CRI |
---|---|---|---|---|---|
LED | 41 W | 5511 lm | 134 lm/W | 4000 K | 80 |
Mounting mode
Wall mounted
Shape and measurements
Length: 1634 mm
Width: 165 mm
Height: 98 mm
Adjustability
Fixed
Electric
System power: 41 W
Protection
IP: 67
IK: 10
Photometric data
ZIP file
