Product data sheet

KOMBIC 100 TK 1500 IP23 9NW RF WFL WH/BK

K11TK1523RW940NWB

Lamp

Product image 1: KOMBIC 100 TK 1500 IP23 9NW RF WFL WH/BK
Product image 1: KOMBIC 100 TK 1500 IP23 9NW RF WFL WH/BK

Product image 1: KOMBIC 100 TK 1500 IP23 9NW RF WFL WH/BK



IP
23

IK
07

LAMP three-phase track downlight model KOMBIC 100. FLOOD reflector made of recycled polycarbonate R-PC FR WHITE TM non-brominated flame retardant additive. Flammability grade V0 according to UL94. Heatsinkmade of die-cast aluminium. COB LED, colour temperature 4000K and CRI90. ON OFF gear included. IP23, IK07 ratings. Insulation Class I. Photobiological safety group 0. LED life time: 50.000 L80 B10 (Ta=25ºC) Available finishes: White and black.

Available equipment Nominal lamp power Lamp flux Luminous efficacy CCT CRI
1 x LED 14.1 W 1406 lm 100 lm/W 4000 K 90
KOMBIC 100 TK 1500 IP23 9NW RF WFL WH/BK

KOMBIC 100 TK 1500 IP23 9NW RF WFL WH/BK

Light output 1

1 x LED

Mounting mode

Ceiling recessed, Contact rail

Shape and measurements

Height: 120 mm

Diameter: 100 mm

Adjustability

Fixed

Electric

System power: 14.1 W

Appliance Class: I

Protection

IP: 23

IK: 07

Photometric data

ZIP file

Download file
