Product data sheet

TUBILUX XT 4500-840 PM L1285 EVG TW

42186408

Zumtobel

Tube luminaire with through-wiring with ø 90 mm, Luminaire luminous flux: 4519 lm, Luminaire efficacy: 141 lm/W. Colour rendering Ra > 80, colour temperature 4000 K. Total power: 32 W, with LED converter; LED service life lasts 73000 h before luminous flux is reduced to 80% of the initial value. Chromaticity tolerance (initial MacAdam): 3. suitable for ceiling mounting and horizontal or vertical wall mounting. Approved for indoor use and in unprotected outdoor areas. ambient temperature: -30°C to +50°C. Housing of impact-resistant (IK07) polymethylmethacrylate, satin, and end caps of polyamide (PA). Age-resistant silicon seal (SI). Gear tray of double coated sheet steel, white. Flexible mounting with stainless steel fixing clips. Electrical connection via cable gland with integrated pressure equalisation element and plug connection terminal. IFS/BRC-compliant. Luminaire wired with halogen-free leads. IPX9K... Dimensions: 1285 x 90 x 105 mm weight: 3.6 kg.

Lamp type Nominal lamp power Total flux Luminous efficacy CCT CRI
LED 32 W 4519 lm 141 lm/W 3000 K 80
TUBILUX XT 4500-840 PM L1285 EVG TW

TUBILUX XT 4500-840 PM L1285 EVG TW

Light output 1 (integrated)

LED

Mounting mode

Ceiling mounted

Shape and measurements

Length: 1285 mm

Width: 90 mm

Height: 105 mm

Weight: 3.6 kg

Design

Material impression: Plastic

Electric

System power: 32 W

Voltage: 220-240 V AC

Protection

IK: 07

Photometric data

ZIP file
