Product data sheet
Circular Outward 3 Rings (ø1200 ø900 ø600)
CF4L-00X9AZOUEF
LedsC4
LedsC4 Circular Outward 3 Rings (ø1200 ø900 ø600) CF4L-00X9AZOUEFV1 Pendant for indoor use. For sideways lighting. Structure finish: Gold. Diffuser material: Polycarbonate. Diffuser finish: Opal. Warranty: 5 Years. Product net weight (Kg): 11 Product width or diameter (mm): 1177 Product height (mm): 6500 Class 1. IP: IP20. LED. No. of lampholders or LEDs: 1. Driver brand: MEANWELL. Maximum power of light source: 153.4W. Colour temperature: 4000K. Colour rendering index: 90. MacAdam Steps: 3. Hours of life: 50.000h L80B20. UGR: 7.4. Photobiological risk: RG1. Real flux (lm): 12782. Real lm/W: 80. Voltage / frequency range: 90-305/50-60Hz. Voltage: 2,8. Equipment included: Yes. Total power: 159. Power factor: 0.90. Dimmable equipment included: ON-OFF.
| Available equipment | Nominal lamp power | Lamp flux | Luminous efficacy | CCT | CRI |
|---|---|---|---|---|---|
| 1 x LED | 69.9 W | 6116 lm | 87 lm/W | 4000 K | 90 |
| Available equipment | Nominal lamp power | Lamp flux | Luminous efficacy | CCT | CRI |
|---|---|---|---|---|---|
| 1 x LED | 51.4 W | 2992 lm | 58 lm/W | 4000 K | 90 |
Mounting mode
Pendant, Table luminaire
Shape and measurements
Length: 1200 mm
Width: 1200 mm
Height: 30 mm
Adjustability
Fixed
Electric
System power: 159 W
Appliance Class: I
Protection
IP: 20
Photometric data
ZIP file
