Product data sheet
Circular Downward 3 Rings (ø2000 ø1200 ø600)
CS4H-00W9AZDUEF
LedsC4
LedsC4 Circular Downward 3 Rings (ø2000 ø1200 ø600) CS4H-00W9AZDUEFV1 Pendant for indoor use. For downlighting. Structure finish: Gold. Diffuser material: Polycarbonate. Diffuser finish: Opal. Warranty: 5 Years. Product net weight (Kg): 0 Product width or diameter (mm): 2060 Product height (mm): 6000 Class 1. IP: IP20. LED. No. of lampholders or LEDs: 1. Driver brand: MEANWELL. Maximum power of light source: 182.5W. Colour temperature: 3000K. Colour rendering index: 90. MacAdam Steps: 3. Hours of life: 50.000h L80B20. Photobiological risk: RG1. Real flux (lm): 15058. Real lm/W: 79. Voltage / frequency range: 90-305/50-60Hz. Voltage: 2,8. Equipment included: Yes. Total power: 190. Power factor: 0.90. Dimmable equipment included: DALI/PUSH.
| Available equipment | Nominal lamp power | Lamp flux | Luminous efficacy | CCT | CRI |
|---|---|---|---|---|---|
| 1 x LED | 127 W | 8108 lm | 64 lm/W | 3000 K | 90 |
| Available equipment | Nominal lamp power | Lamp flux | Luminous efficacy | CCT | CRI |
|---|---|---|---|---|---|
| 1 x LED | 69.5 W | 4633 lm | 67 lm/W | 3000 K | 90 |
Mounting mode
Pendant, Table luminaire
Shape and measurements
Length: 2000 mm
Width: 2000 mm
Height: 45 mm
Adjustability
Fixed
Electric
System power: 234 W
Appliance Class: I
Protection
IP: 20
Photometric data
ZIP file
