Installation Surface mounted, cable wire, wire suspension or on a wall. Installation using the seal supplied with the luminaire provides protection classification IP 44. With wall mounting or installation without seals the luminaire is classified IP 40. Connection Connects via 230 V, built-in LED driver. Four Ø 19 mm access holes with blanking grommets on top of the luminaire and one Ø 16 mm knock-out in each end. The centrally positioned snap-in terminal block 5x2.5 mm² provides through-wiring. The luminaire is also available with 3-phase - 1-phase+Dali - 5x1.5 mm² or 5x2,5 mm² through-wiring and snap-in terminal blocks at each end. Design Body in white enamelled, corrosion resistant aluzinc RAL 9016. End-caps of PP polypropene. Louvre Clear cover of extruded acrylic plastic with prismatic underside and lined sides. Opal diffuser is available as an accessory. General info The articles below are examples. Use Fagerhult Configure to customise and optimise your version of Allfive by selecting switching options, luminous flux, accessories, etc.
