Product data sheet

Circular Inward ø1200 Recessed

CD5B-00V9AZRU05

LedsC4

LedsC4 Circular Inward ø1200 Recessed CD5B-00V9AZRU05V1 Pendant for indoor use. For uplighting and downlighting. Structure finish: Black. Diffuser material: Polycarbonate. Diffuser finish: Opal. Warranty: 5 Years. Product net weight (Kg): 6 Product width or diameter (mm): 1209 Product height (mm): 3000 Ø of the hole for recessing (mm): 100 Class 1. IP: IP20. LED. No. of lampholders or LEDs: 1. Driver brand: MEANWELL. Maximum power of light source: 67.4W. Colour temperature: 2700K. Colour rendering index: 90. MacAdam Steps: 3. Hours of life: 50.000h L80B20. UGR: 7.5. Photobiological risk: RG1. Real flux (lm): 3708. Real lm/W: 52. Voltage / frequency range: 90-305/50-60Hz. Voltage: 2,8. Equipment included: Yes. Total power: 72. Power factor: 0.90. Dimmable equipment included: 0-10V.

Available equipment Nominal lamp power Lamp flux Luminous efficacy CCT CRI
1 x LED 72 W 3708 lm 52 lm/W 2700 K 90
Circular Inward ø1200 Recessed

Circular Inward ø1200 Recessed

Light output 1

1 x LED

Mounting mode

Pendant, Table luminaire

Shape and measurements

Length: 1200 mm

Width: 1200 mm

Height: 30 mm

Adjustability

Fixed

Electric

System power: 72 W

Appliance Class: I

Protection

IP: 20

Photometric data

ZIP file
