Product data sheet
Circular Inward 3 Rings (ø2000 ø1200 ø600)
CD4H-00V9AZOU05
LedsC4
LedsC4 Circular Inward 3 Rings (ø2000 ø1200 ø600) CD4H-00V9AZOU05V1 Pendant for indoor use. Structure finish: Black. Diffuser material: Polycarbonate. Diffuser finish: Opal. Warranty: 5 Years. Product net weight (Kg): 0 Product width or diameter (mm): 2074 Product height (mm): 6000 Class 1. IP: IP20. LED. No. of lampholders or LEDs: 1. Driver brand: MEANWELL. Maximum power of light source: 227W. Colour temperature: 2700K. Colour rendering index: 90. MacAdam Steps: 3. Hours of life: 50.000h L80B20. Photobiological risk: RG1. Real flux (lm): 12392. Real lm/W: 53. Voltage / frequency range: 90-305/50-60Hz. Voltage: 2,8. Equipment included: Yes. Total power: 234. Power factor: 0.90. Dimmable equipment included: ON-OFF.
| Available equipment | Nominal lamp power | Lamp flux | Luminous efficacy | CCT | CRI |
|---|---|---|---|---|---|
| 1 x LED | 127 W | 6459 lm | 51 lm/W | 2700 K | 90 |
| Available equipment | Nominal lamp power | Lamp flux | Luminous efficacy | CCT | CRI |
|---|---|---|---|---|---|
| 1 x LED | 69.5 W | 3708 lm | 53 lm/W | 2700 K | 90 |
Mounting mode
Pendant, Table luminaire
Shape and measurements
Length: 2000 mm
Width: 2000 mm
Height: 30 mm
Adjustability
Fixed
Electric
System power: 234 W
Appliance Class: I
Protection
IP: 20
Photometric data
ZIP file
