Emergency luminaire With LED GRP Explosion-protected Type: 6409/4128-5103-162-1110-11 -850011 Enclosure material: Polyester resin Translucent cover material: Polycarbonate Version: Standard Number of lamps: 1 Lamp wattage: 25 W Dimensions (L x W x H): 857 x 183,5 x 125 mm AC rated operational voltage: 110,00 - 240,00 V Application range (zones): 2 , 21, 22 Gas explosion protection: II 3 G Ex db ec IIC T4 Gc Dust explosion protection: II 2 D Ex tb op is IIIC T100 °C Db II 3 D Ex tc IIIC T100 °C Dc Min. ambient temperature: -30 °C Max. ambient temperature: +50 °C Through wiring: With 6 conductors 2.5 mm2 Installed terminal strip: PE + N + L1 + L2 + L3 + L´ Max. solid connect. terminals: 6,00 mm2 Max. fine. strand. conn. term.: 4,00 mm2 Battery capacity: 7 Ah Battery version: NiCd battery, gas-tight Emergency light operation: Continuous light Or stand-by light Operating time: 1.5 h em. lighting operation Battery operating voltage: 6 V Self-test function: With (standard) Drilled holes: 3 x M25 Accessories: Provided Screw connections: 2 x M25 Ø 7 – 17 mm Cable entry material: Polyamide, black Stopping plug: 2 x M25 x 1.5 Stopping plug material: Polyamide, black For further information, see: www.r-stahl.com WebCode 6409C
