Product data sheet

LUGTRACK 2 LED 3000 6000lm 3000K opal plexiglass (PLX) white

080101.5L14.21

LUG

Product image 1: LUGTRACK 2 LED 3000 6000lm 3000K opal plexiglass (PLX) white
Product image 1: LUGTRACK 2 LED 3000 6000lm 3000K opal plexiglass (PLX) white

Product image 1: LUGTRACK 2 LED 3000 6000lm 3000K opal plexiglass (PLX) white



IP
20

IK
05

Modern LED luminaire for quick assemby, construction of the luminaire enables quick, easy and tool-less connection into long lighting systems (available in 1,5m and 3m-long dimension) by the usage of mounting elements. Mounting: suspended, on wire suspension (on request) Body: coated steel sheet Power: 220-240V 50/60Hz Lifetime (L80B10): 50 000 h Operating temperature range: 0˚C ... +45˚C Available on request: DALI, LED emergency module Additional information: Mounting bracket 150110.[more]

Lamp type Nominal lamp power Total flux Luminous efficacy CCT CRI
LED 52 W 3000 lm 58 lm/W 3000 K 80
LUGTRACK 2 LED 3000 6000lm 3000K opal plexiglass (PLX) white

LUGTRACK 2 LED 3000 6000lm 3000K opal plexiglass (PLX) white

Light output 1 (integrated)

LED

LOR:100%
Total power:52 W

Mounting mode

Pendant

Shape and measurements

Length: 3000 mm

Width: 129 mm

Height: 57 mm

Adjustability

Fixed

Design

Colour of housing: White

Electric

System power: 52 W

Appliance Class: I

Protection

IP: 20

IK: 05
