Product data sheet

Iris Trimless Pipe 35º

AV15-18V9Z2DSL7

LedsC4

LedsC4 Iris Trimless Pipe 35º AV15-18V9Z2DSL7 Pendant for indoor use. Structure material: Aluminium. Structure finish: Black/Black/Black. Warranty: 5 Years. Product net weight (Kg): 0.48 Product width or diameter (mm): 55 Product height (mm): 1705 Ø of the hole for recessing (mm): 57 Permitted ceiling thickness: 0-20 Class 2. Luminaire not suitable for coating with insulation materials. IP: IP43. LED. No. of lampholders or LEDs: 1. LED brand: CREE. Maximum power of light source: 16.4W. Colour temperature: 2700K. Colour rendering index: 92. MacAdam Steps: 2. Hours of life: 50.000h L80B20. UGR: 26.5. Photobiological risk: RG1. % de Flickering: <5%. Real flux (lm): 1841. Real lm/W: 100. Voltage / frequency range: 110-277/50-60Hz. Voltage: 33,7. Equipment included: Yes. Total power: 18.5. Power factor: 0.90. Dimmable equipment included: DALI-2.

Available equipment Nominal lamp power Lamp flux Luminous efficacy CCT CRI
1 x LED 18.5 W 1841 lm 100 lm/W 2700 K 90
Iris Trimless Pipe 35º

Iris Trimless Pipe 35º

Light output 1

1 x LED

Mounting mode

Pendant, Table luminaire

Shape and measurements

Length: 2.17 in

Width: 2.17 in

Height: 6.69 in

Adjustability

Fixed

Electric

System power: 18.5 W

Appliance Class: II

Protection

IP: 43

Photometric data

ZIP file
