Product data sheet
Colour
501004.003
RZB
Series: Colour Type of Protection: IP 44 Protection Class: II Voltage: - 250 / 0 - 60 Hz Base and protective cage: plastic. Two cable inlets. Cover: textured glass, transparent. Protective cage fastening with screws. Available Colours: jet black (RAL 9005) Type of Installation: Ceiling mounting, Wall (surface) Dimensions: D 200, H 100 Lamp: 1 x E27 max. 100 W Socket 1: E27 Operating Mode Lamp 1: Converter not necessary Safety Marks: F-mark Impact Protection: IK07 (2 Joule) Beam Angle: 171°/122° Unified Glare Ratio: 19,3 EEC: A++ - E
| Available equipment | Nominal lamp power | Lamp flux | Luminous efficacy | CCT | CRI |
|---|---|---|---|---|---|
| 1 x Compact fluorescent lamp | 15 W | 970 lm | 32 lm/W | 2700 K | 80 |
Mounting mode
Wall mounted
Shape and measurements
Height: 6.30 in
Diameter: 7.87 in
Adjustability
Fixed
Design
Color of housing: Black
Electric
System power: 15 W
Protection
IP: 44
IK: 07
Photometric data
ZIP file
